Design and Features
Basic Performance Specifications
Design and Features
Dual-Sensor Imaging System
With high-quality visible and thermal cameras, it ensures clear imaging and accurate detection in any environment, day or night.
4K Ultra HD Imaging
Equipped with an 8MP 1/2.8" CMOS sensor, capable of recording video at up to 3840×2160 resolution at 30fps.
Dual-Axis Stabilized Gimbal
Integrated with a dual-axis stabilization system providing ±0.01° accuracy, ensuring stable image output in motion or vibration-prone environments.
Precision Operation
Supports full-range PTZ control and zoom functionality, allowing flexible and accurate imaging from various angles.
Quick-Release Design
Slide-rail quick release system enables fast installation and removal, improving flexibility and maintenance efficiency.
Water Resistance Rating
Equipped with IP56 protection, it prevents dust ingress and withstands water splashes, ensuring consistent outdoor operation.
Basic Performance Specifications
| DD3000B | |
| basic spec. | |
| Input Voltage | 12 - 50V |
| Power | 8.4W |
| Weight | 905.9g |
| Dimension | 122 * 130 * 165mm |
| Operating Temp. | -10℃ ~ 65℃ |
| Storage Temp. | -20℃ ~ 70℃ |
| Memory Card | Micro SD Card |
| Interface | RJ45 Ethernet (IP) / TTL/POWER |
| Water Resistance Rating | IP55 |
| Gimbal | |
| Angle Vibration | ±0.008° |
| Control Range | Pitch: +45° to -90°, Yaw: 360° |
| Structure Range | Pitch: +55° to 235°, Yaw: 360° |
| Control Speed | Pitch: 120°/s, Yaw: 180°/s |
| EO | |
| CMOS | 1/2.8" Sony Starvis CMOS Sensor |
| Pixel | 8M pixels |
| Optical Zoom | 30x"(for magnification or zoom) F=4.8mm ~ 144 mm |
| F-number | F1.5 ~ F3.4 |
| FOV | 3.07°–57.05°(Horizontal) ; 1.6°–34.04°(Vertical) |
Resolution |
3840x2160 @ 30fps 2592x1520 @ 30fps 1920x1080 @ 30fps 1280x720 @ 30fps 640x480 @ 30fps |
| DRI（M）(1.8m*0.5m) | D : 17010 R : 4250 I : 2130 |
| Vid | H.264+ / H.264 / M-JPEG |
| LFR | |
| Laser Wavelength | 905 ± 20nm |
| Measure Range | 5 meters ~ 3,600 meters |
| Laser Power | Class 2, <1mW |
| Accuracy | ±0.4% x Distance |
