Design & Features
Basic Performance Specifications
Design & Features
Precise Motor Control
Equipped with high-performance chips and advanced algorithms for smooth and responsive control.
Stable Power Output
Integrated power management ensures stable voltage/current, protecting against overheating and overload.
Efficient Heat Dissipation
Built-in cooling system efficiently regulates temperature, enhancing performance and extending product life.
Enhanced Stability
High-quality materials and circuit design provide excellent anti-interference capabilities for reliable operation in complex environments.
Made in Taiwan
Crafted with precision manufacturing for durable and long-lasting performance.
Flexible Compatibility
Easily integrates with various UAVs and electronics, simplifying installation for diverse applications.
Basic Performance Specifications
| Specifications | ||
| Item No | KTP-PM0002 | |
| Input Voltage | 9-26 Volts (4S~6S) | |
ESC (4-in-one) |
Continue Current | 4*15A = 60 A |
| Max. Burst Current | 4*20A = 80 A | |
DC/DC Convert Output Voltage |
5V *1 Set (Max.3A / 15W ) 12V*1Set (Max. 5A / 60W ) |
|
| Communication | Voltage / Current .-UART PWM (in) * 4- PWM |
|
| Baurate | 115200 | |
| Dimension | 45*85*9.2 mm | |
| Weight (wo/Cables) | 36g | |
